ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC

ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC

1.199,00 €
2.100,00 €
1.199,00 €
Save 901,00 €
🔥 Official Store Exclusive
40€ OFF
⚡ Standard/Pro Discount Already Applied
Lowest Price: 1159 €
ACE40
00Days
00H
00Min
00Sec



CPU: AMD Ryzen™ AI 9 HX 470
TYPE: Pro | 32GB SO-DIMM + 1TB SSD (Upgradable)
Please hurry! Only 22 left in stock
Subtotal: 1.199,00 €

Shipping Guarantee

Shipped from Warehouse in Germany

Free Standard Shipping within Europe

Shipping Policy

Warranty

30-Day Hassle-Free Return Policy

2-Year Warranty

Lifetime Technical Support

Warranty Policy

ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC

ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC

2.100,00 € 1.199,00 €
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC
ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC

ACEMAGIC F5A AMD Ryzen AI9 HX 470 Mini PC

2.100,00 € 1.199,00 €
CPU: AMD Ryzen™ AI 9 HX 470
TYPE: Pro | 32GB SO-DIMM + 1TB SSD (Upgradable)
Description
Standard
Processor AMD Ryzen™ AI 9 HX 470 Processor, 12 Cores / 24 Threads
(4× Zen 5 + 8× Zen 5c Architecture, TSMC 4nm FinFET, 12 MB L2 Cache + 24 MB L3 Cache, Base Frequency 2.0 GHz, Turbo up to 5.2 GHz)
AMD Ryzen™ AI Engine (XDNA2 Architecture) with Integrated NPU
Up to 55 TOPS NPU Performance, Total AI Performance (CPU+GPU+NPU) up to 86 TOPS
Graphics Card AMD Radeon™ 890M (RDNA 3.5 Architecture, 16 Compute Units, GPU Clock up to 3.1 GHz)
RAM Onboard LPDDR5X Memory (Soldered, Non-upgradable)
32 GB LPDDR5X 8000 MT/s
Storage Configuration 1 TB M.2 2280 NVMe PCIe 4.0 ×4 SSD (Pre-installed)
3 × M.2 2280 NVMe Slots (1× PCIe 4.0 ×4, 2× PCIe 4.0 ×2)
Supports PCIe 4.0 NVMe SSDs
Maximum Capacity: Up to 12 TB (Up to 4 TB per Slot, SATA Not Supported)
Wireless Connectivity Wi-Fi 7 + Bluetooth 5.4 (M.2 2230)
Video Output HDMI 2.1 ×1 (Up to 8K@60Hz)
USB4 Type-C ×2 (DP 1.4, Up to 40 Gbps, 8K@60Hz, PD 100W Input / 15W Output)
DP 2.1 ×1 (Up to 8K@60Hz)
Audio Output 3.5 mm Audio Jack ×1
Ports & Buttons RJ45 Ethernet Port ×2 (10/100/1000 Mbps / 2.5 Gbps Adaptive, Dual 2.5G LAN)
USB 3.2 Gen2 Type-A ×2 (10 Gbps, Front Panel)
USB 3.2 Gen2 Type-A ×1 (10 Gbps, Rear Panel)
USB 2.0 Type-A ×1 (Rear Panel)
USB4 Type-C ×2 (DP 1.4, Up to 40 Gbps, PD 100W Input / 15W Output)
DC-IN ×1
HDMI 2.1 ×1
DP 2.1 ×1
3.5 mm Audio Jack ×1
OCuLink Port ×1 (Supports External GPU Connection)
Power Button ×1
Power Supply DC 19V / 6.3A, 5.5 × 2.5 mm
Operating System Windows 11 Pro (Pre-installed), Supports Linux and Ubuntu
Dimensions Color: Sabi Tone (Metal + Plastic)
130 × 132 × 62 mm
Weight: Approx. 650 g (Net) / 1.6 kg (Gross)
Pro
Processor AMD Ryzen™ AI 9 HX 470 Processor (SO-DIMM Version), 12 Cores / 24 Threads
(4× Zen 5 + 8× Zen 5c Architecture, TSMC 4nm FinFET, 12 MB L2 Cache + 24 MB L3 Cache, Base Frequency 2.0 GHz, Turbo up to 5.2 GHz)
AMD Ryzen™ AI Engine (XDNA2 Architecture) with Integrated NPU
Up to 55 TOPS NPU Performance, Total AI Performance (CPU+GPU+NPU) up to 86 TOPS (FP8)
TDP: Standard 54W, Maximum up to 65W (BIOS Adjustable in 3 Levels: 45W / 54W / 65W)
Graphics Card AMD Radeon™ 890M (RDNA 3.5 Architecture, 16 Compute Units, GPU Clock up to 3.1 GHz)
RAM 32 GB (2× 16 GB) SO-DIMM DDR5 5600 MHz Dual-Channel
2× DDR5 SO-DIMM Slots (Supports DDR5-5600)
Maximum Capacity: Up to 128 GB
Storage Configuration 1 TB M.2 2280 NVMe PCIe 4.0 ×4 SSD (Pre-installed)
2× M.2 2280 NVMe Slots (2× PCIe 4.0 ×4)
Supports PCIe 4.0 ×4 NVMe SSDs
Maximum Capacity: Up to 4 TB per Slot (Total up to 8 TB)
Wireless Connectivity Wi-Fi 7 + Bluetooth 5.4 (M.2 2230)
Video Output HDMI 2.1 ×1 (Up to 8K@60Hz)
USB4 Type-C ×2 (DP 1.4, Up to 40 Gbps, 8K@60Hz, PD 100W Input / 15W Output)
DP 2.1 ×1 (Up to 8K@60Hz)
Audio Output 3.5 mm Audio Jack ×1
Ports & Buttons RJ45 Ethernet Port ×2 (2.5 GbE LAN, Dual 2.5G LAN)
USB 3.2 Gen2 Type-A ×2 (10 Gbps, Front Panel)
USB 3.2 Gen2 Type-A ×1 (Rear Panel)
USB 2.0 Type-A ×1 (Rear Panel)
USB4 Type-C ×2 (Supports DP 1.4, 8K@60Hz, Up to 40 Gbps Data Transfer, PD 15W Output, PD 100W Input)
DC-IN ×1
HDMI 2.1 ×1
DP 2.1 ×1
3.5 mm Audio Jack ×1
OCuLink Port ×1 (Supports External GPU Connection)
Power Button ×1
Power Supply DC 19V / 6.3A, 5.5 × 2.5 mm Connector
Operating System Windows 11 Pro (Pre-installed), Supports Linux and Ubuntu
Dimensions & Weight Color: Sabi Tone / Rust Gray (Metal + Plastic)
130 × 132 × 62 mm
Weight: Approx. 650 g (Net) / 1.6 kg (Gross)
Cooling & Airflow Top Air Intake, Rear Air Exhaust
Dual-Fan Cooling System (CPU Fan + System Fan) with VC Vapor Chamber
Performance Delivery (TDP) up to 65W
Package Contents 1× Mini PC Host, 1× User Manual, 1× HDMI Cable, 1× VESA Mount, Screw Set, 1× Power Adapter
Special Features 1. OCuLink Port for Seamless Connection of External GPUs (eGPU)
2. High-Efficiency VC Vapor Chamber Cooling with Dual Fans Supporting up to 65W TDP Performance
3. Removable Bottom Panel for Easy Upgrades of DDR5 RAM and NVMe SSDs
4. Quad Display Support: Simultaneous 4K/8K Output via HDMI 2.1, DP 2.1, and Dual USB4 Ports
5. Powered by the Latest AMD Ryzen™ AI 400 Series (Ryzen AI 9 HX 470) with Total AI Computing Performance of 86 TOPS
6. Wi-Fi 7 and Dual 2.5G LAN Ports for Ultra-Fast Network Connections
7. Two Full-Function USB4 Type-C Ports (40 Gbps, DP 1.4 8K@60Hz, PD 100W Input / 15W Output)
8. Extensive I/O Interfaces for Maximum Connectivity
9. Ultra-Compact Premium Metal Chassis Design
10. Optimized 32 GB + 1 TB Configuration: Supports Smooth Local Execution of 7B–14B Class LLMs (Large Language Models)
11. Windows 11 Pro Pre-installed, Fully Compatible with Linux and Ubuntu
Standard vs. Pro: Key Differences
WHY PRO? / IN-DEPTH COMPARISON

Why You Must Choose the SO-DIMM Upgradable Pro Version

As a future-proof AI workstation, expandability dictates hardware lifespan. Compared to the soldered RAM version, Product 2 (SO-DIMM Version) brings a revolutionary leap in upgrade potential and NVMe transfer efficiency.

LPDDR5X Soldered Edition (Product 1)

For basic use, fixed budgets, and zero future RAM upgrade needs.

  • ✓ AMD Ryzen™ AI 9 HX 470 Flagship CPU
  • ✗ RAM is permanently soldered (Locked at 32GB)
  • ✗ 2 of 3 M.2 slots run at half-speed PCIe 4.0 x2
  • ✗ RAM bottlenecks when running 30B+ local AI models

SO-DIMM Upgradable Pro (Product 2 - Recommended)

The ultimate workstation for AI devs, AAA gamers, and creators.

  • ✓ AMD Ryzen™ AI 9 HX 470 Flagship CPU (86 TOPS)
  • ✓ Dual SO-DIMM slots, expandable up to 128GB RAM2x Lifespan
  • ✓ Both M.2 NVMe slots are Full-Speed PCIe 4.0 x47000+ MB/s
  • ✓ Ultimate DIY Freedom: Tool-friendly access to RAM/SSD
Hardware Spec Product 1: LPDDR5X Soldered RAM Product 2: SO-DIMM Upgradable Pro [Recommended]
Processor & AI TOPS Ryzen™ AI 9 HX 470 (86 TOPS Total / 55 TOPS NPU) Ryzen™ AI 9 HX 470 (86 TOPS Total / 55 TOPS NPU)
RAM Architecture
★ Core Difference 		32GB LPDDR5X 8000MT/s (Soldered Onboard)
Non-upgradable 		32GB (2×16GB) DDR5 SO-DIMM (Dual Slots)
Supports free expansion up to 128GB massive RAM! Geek Choice
NVMe SSD Channels
★ Speed Difference 		3 × M.2 Slots (12TB Max)
Only 1*PCIe 4.0 x4 full speed (2 run at half speed x2)		 2 × M.2 Slots (8TB Max)
Both 2*PCIe 4.0 x4 are full-speed independent lanes! Zero Bottleneck
DIY & Resale Value Only SSD can be upgraded. RAM failure ruins motherboard. Easy upgrades of both RAM and SSDs. Extends lifespan by 3-5 years with higher resale value! +3-5 Yrs Lifespan
eGPU & Connectivity OCuLink Port + Dual 2.5G LAN + WiFi 7 + Dual USB4 (8K) OCuLink Port + Dual 2.5G LAN + WiFi 7 + Dual USB4 (8K)

Unleash True AI Workstation Potential — Don't Limit Your Future

Choose the SO-DIMM Upgradable Pro Version to enjoy up to 128GB RAM upgradeability and dual full-speed PCIe 4.0 x4 transfers. A smart investment today ensures your hardware stays powerful for years to come.

Shop SO-DIMM Pro Edition Now (Limited Geek Discount) →
